Application





Automatic Filter
In all Automatic Filters the filter candles, wedgewire candles or wire mesh candles are automati-cally cleaned without interruption to operationby backflushing. Cleaning can be performed bythe filtrate fluid, filtrate fluid accelerated bycompressed air or by external medium and maybe initiated by differential pressure or time.Filters of this type are employed when manualcleaning is uneconomical due to the continuingnature of contamination, or when the produc-tion process is totally automated.





Filtration Layers
Information



Type of weave: Special twistVersion: 24 Mesh no.: 400/40 Mesh size (u m) (absolute): 25Nomin. Grade of filtration ( u m):10Passage area(%): 44	Type of weave: Special twistVersion: 19 Mesh no.: 294/31 Mesh size u m) (absolute): 34Nomin. Grade of filtration ( u m):20Passage area(%): 44	Type of weave: Special twistVersion: 15 Mesh no.: 208/26 Mesh size (u m) (absolute): 48 Nomin. Grade of filtration u m):30Passage area(%): 44
Type of weave: Special twist Version: 26 Mesh no.: 155/19 Mesh size (u m) (absolute): 60Nomin. Grade of filtration ( u m):45Passage area(%): 44	Type of weave: Special twist Version:11 Mesh no.:128/18Mesh size (u m) (absolute): 80Nomin. Grade of filtration ( u m):60Passage area(%): 44	Type of weave: Five heddle-twilled-weaveVersion:30 Mesh no.: 5110 Mesh size (u m)(absolute): 80 Nomin. Grade of filtration ( u m):60Passage area(%): 2
